ALFK-300 Series Sided-mounted Float Ball Level Switch
Product Description
Float level switches are suitable for liquid level control when the measured liquid level in the liquid storage equipment and storage & transportation tools in industries such as chemical, petroleum, and ship industries reaches a given point.
Such switches enable the contact switch to work based on the leverage principle and magnetic action, thus controlling the liquid level in situations that require frequent operation at the liquid level positions.
Technical Data
-
Model
ALFK-301
-
Explosion Proof Grade
Exd IIC T4~T6
-
Operating Pressure
-0.1~10MPa
-
Operating Temperature
0~350℃
-
Control Range
≤ 10mm
-
Adjustment Mode
Non adjustable
-
Installation Mode
Side mounted
-
Power Supply and Contact Capacity
220VAC/DC 150W
-
IP Rating
IP65
-
Model
ALFK-302
-
Explosion Proof Grade
Exd IIC T4~T6
-
Operating Pressure
-0.1~10MPa
-
Operating Temperature
0~350℃
-
Control Range
25~550mm
-
Adjustment Mode
Adjustable
-
Installation Mode
Side mounted
-
Power Supply and Contact Capacity
220VAC/DC 150W
-
IP Rating
IP65
