AL2000 Magnetic Flap Level Gauge

Product Description

AL2000 series magnetic level gauge can be used to detect the liquid level (interface) of liquid media in equipment made of various materials. Because the detection part of level gauges in this series is completely isolated from the display part, it has unique advantages in measuring the liquid level of high temperature, high pressure, high viscosity, toxic, harmful and strongly corrosive media.Coupled with a level control and alarm switch, the series of level gauges realize level control, alarm, and linkage.


Features

  • icon13.svg
    High accuracy

    • 10mm

  • icon14.svg

    • Can be installed sideways or from the top

  • icon15.svg

    • Various options for high-temperature and high-pressure applications

  • icon16.svg

    • Available in regular and corrosion-resistant models

  • icon17.svg

    • Multiple material options for floating ball and measuring cylinder, including 316L and others

  • icon18.svg

    • Multiple lining materials: 304, 316, 316L, Hastelloy, PTFE painting, etc.

  • icon19.svg

    • Diverse communication modes: 4-20mA+HART+Level switch (HART offers active and passive output options)

  • icon01.svg

    • Wide range of process connection options: Flange conforms to GB + ASME/ANSI + GOST + JIS + EN

  • icon02.svg

    • IP rating: IP65

Technical Data

  • Type

    Side mounted,Top mounted

  • Wetted Part Material

    SS304,SS316,SS316L,PP,PTFE

  • Measurement Range

    0~15000mm (C-C length ≥300mm)

  • Design Temperatu

    -15~420℃

  • Design Pressure

    -0.1 ~16.0MPa

  • Built-in Remote Transmitter & Bundled Remote Transmitter

    Selectable

  • Measurement Range

    0~8000mm (single piece), and segmented connection is for overlength

  • Measurement Accuracy

    2.5% for H ≤ 1000mm and 1.5% for H>1000mm

  • Resolution

    10mm (max. 5mm)

  • Output Signal

    4~20mADC two-wire

  • Explosion-proof Type

    Explosion-proof Exd IIC T4~T6, intrinsically safe Exia IIC T4~T6

  • Power Supply Voltage

    24VDC

  • Communication Protocol

    HART (optional)

  • Supporting Panel (indicator) Material

    Aluminum alloy, stainless steel 304 (selectable)
