AL2300 Magnetic Float Ball Level Gauge

Product Description

AL2300 series magnetic float level transmitter mainly consists of level sensor and current converter. It uses the magnetic float change of rising and dropping along the guide rod of the level sensor, so that the resistance signal in the sensor changes linearly, and then the current converter converts this resistance signal into a two-wire 4~20mADC current signal to realize the remote transmission of the level signal.


Features

  • icon03.svg
    High accuracy

    • 10mm

  • icon04.svg

    • Can be installed laterally or from the top

  • icon05.svg

    • Various options for high-temperature and high-pressure applications

  • icon06.svg

    • Available in regular and corrosion-resistant models

  • icon07.svg

    • Multiple material options for floating ball and measuring cylinder, including 316L and others

  • icon08.svg
    Diverse communication modes

    • 4-20mA+HART+Level switch (HART offers active and passive output options)

  • icon09.svg
    Wide range of process connection options

    • Flange conforms to GB + ASME/ANSI + GOST + JIS + EN

  • icon10.svg
    IP rating

    • IP65

Technical Data

  • Measurement Range

    0~300mm to 6000mm

  • Measurement Accuracy

    ±10mm

  • Output Signal

    Two-wire 4~20mA

  • Electrical Interface

    M20×1.5 internal thread

  • Operating Temperature

    -15° C~120° C

  • Medium Density

    ≥ 0.64g/cm3

  • Operating Pressure

    -0.1MPa~4.0MPa

  • Medium Viscosity

    ≤ 0.02PaS

  • Wetted Part Material

    304, 316L, PTFE and PP (positioned according to medium and working conditions)

  • Transmitter Power Consumption

    ≤ 1W

  • Transmitter Power Supply

    24VDC (the company's instruments come with a 24VDC feed output)

  • Ambient Temperature

    -40℃ ~60℃

  • Load Impedance

    ≤ 600Ω

  • Protection Grade

    IP65

  • Explosion-proof Grade

    Intrinsically safe Exia IIC T4~T6Ga flameproof Exd IIC T4~T6

  • Connecting Flange Standard

    HG20592-20635-97. Other standards (such as GB, JB, ANSI, and JIS) used by the user shall be indicated at the time of ordering
