4100 Guided Wave Radar Level Transmitter
About 4100 Guided Wave Radar Level Transmitter
HollySys 4100 Guided Wave Radar Level Transmitter guides the microwave pulse downwards onto the measured medium through a waveguide rod, and some signals are re flected back. The level is determined by measuring the time difference between signal transmission and reception.
Product Features
-
Reliability"ELL signal analysis technology" can reduce the impact of various false echoes to ensure high reliability of products.
-
SafetyIt is designed and produced based on IEC61508 stan dard to ensure high safety of products.
-
Double Cavity EnclosureIt fully realizes the isolation of circuit cavity to ensure the safety of using electricity on-site.
-
Lightning ProtectionDHE G80 is equipped with built-in light ning surge protection to protect the instrument from lightning interference.
-
High PrecisionIt adopts FMCW frequency modulation tech nology, and the product accuracy can reach ± 1 mm.
-
Small Beam AngleIt adopts the beam angle of 3° technology, which greatly improves the anti-interference ability.
-
Small Blind ZoneIt adopts small blind zone technology which can reduce the blind zone to a minimum of 2 cm.
-
Millimeter WavelengthIt adopts millimeter wavelength technology, which has the ability to penetrate smoke, dust and fog, and is suitable for complex working con ditions.
Technical Parameters
-
DHE-RD-4100-1
-
Antenna
Cable antenna
-
Dielectric constant
＞ 1.2
-
Measurement range
0 to 30 m
-
Process connection
Thread/flange
-
Process temperature
-40 to 500℃
-
Process pressure
-0.1 to 20.0 MPa
-
Accuracy
±3 mm
-
Output signal
4 to 20 mA, HART 7; Modbus RTU
-
Display
LCD display
-
Explosion-proof/protection grade
Ex ia IIC T6 Ga/IP66/IP68
-
Frequency
1.8 GHz
-
DHE-RD-4100-2
-
Antenna
Pole antenna
-
Dielectric constant
＞ 1.2
-
Measurement range
0 to 6 m
-
Process connection
Thread/flange
-
Process temperature
-40 to 500℃
-
Process pressure
-0.1 to 20.0 MPa
-
Accuracy
±3 mm
-
Output signal
4 to 20 mA, HART 7; Modbus RTU
-
Display
LCD display
-
Protection grade
Ex ia IIC T6 Ga/IP66/IP68
-
Frequency
1.8 GHz
