DK800 Glass Tube Float Flowmeter
Product Description
The DK800 glass tube flowmeter is used to measure the volumetric flow of liquids and gases. It is suitable for various applications requiring precise flow measurement, such as supply flow monitoring for meteorological chromatography analyzers and micro-flow monitoring of target samples in other analytical systems. Additionally, it can be connected to different types of pressure regulators to ensure the inlet or outlet pressure of the flowmeter remains stabilized.
Features
-
No moving parts inside, easy installation and maintenance
-
Digital filter amplifier with wider measurement range and better anti-interference performance
-
Flow ratio (turndown) up to 33:1
-
High accuracy up to ±0.2%
-
Max temperature up to +420ºC
-
Inline and insertion types
-
Integrated and remote mounting options
-
Power-off record function
-
Remote mounting type supports pressure and temperature compensation
-
CE and calibration certification
Technical Data
-
Application range
Used for flow measurement of liquid and gas
-
Accuracy grade
G=2.5%, qG=50%, according to VDI/VDE 3513, Table 2
-
Operating pressure PS
PED97/23/EC
-
Test pressure PT
PED97/23/E
-
Maximum allowable operating pressure PS (TS=100ºC)
-
DK…/R
10 bar
-
DK…/N
10 bar
-
DK…/PV
4 bar
