A450-V-F Fluorine Lined V-shaped Ball Valve
Product Description
Valves for applications with strict sealing requirements, especially suitable for strong corrosive media.
Features
-
Valve body made of F46 or PFA lined cast steel available
-
Fluoroplastics of PTFE and FEP selected, enabling superior corrosion resistance and excellent sealing performance
-
Rotation between the valve element and the valve seat featuring no clearance, with large shear force and self-cleaning performance
-
Proportional adjustment available if equipped with valve positioner
-
Simple structure, easy for maintenance
Technical Data
-
Nominal Diameter
DN15 ~ DN250, NPS 1/2'' ~ 10''
-
Nominal Pressure
PN10 ~ PN16, ASME CL150
-
Temperature Range
-30° C ~ +150° C
-
Standards
Complying with GB, ANSI and other standards
-
Supporting Actuator
Matching with 830 actuator
