A450-G0 Fixed Soft/Hard Seal Ball Valve
Product Description
Control valves for applications that require tight cut-off and low adjustment requirements in various industries.
Features
-
Various valve body materials for selection, such as cast steel, cast stainless steel, low-temperature and high-alloy steel or special materials
-
With upper and lower shafts used to fi x the ball, the ball will not move from side to side due to the influence of pipe pressure, so the valve seat will not be damaged and provide sealing performance
-
The valve seat is designed to be supported by spring to press the ball, the valve seat features small torque and stable sealing performance that lead to a long service life
-
Fire-proof, anti-static and anti-blowout stem structure for selection
-
Suitable for various working conditions with soft and hard sealing for selection and hardenable sealing surface
Technical Data
-
Nominal Diameter
DN40 ~ DN400, NPS 1-1/2'' ~ 16''
-
Nominal Pressure
PN16 ~ PN63, ASME CL150, CL300
-
Temperature Range
-60° C ~ +540° C
-
Standards
Complying with GB, ANSI and other standards
-
Supporting Actuator
Matching with 830 actuator
