A400 Eccentric Half-ball Valve

Product Description

Control valves for process industry and industrial application.


Features

  • icon03.svg
    • Various valve body materials for selection, such as cast steel, cast stainless steel, low-temperature and high-alloy steel or special materials

  • icon04.svg
    • Very small torque on the valve element and valve stem during valve opening and closing due to the fact that they only perform rotational motions

  • icon05.svg
    • Very small leakage and lower thrust of the actuator required to close the valve when compared with that of the ball valve and butterfly valve

  • icon06.svg
    • Small valve body volume, light weight and excellent adjustment and cut-off performance

  • icon07.svg
    • Simple flow path, large flow capacity and long service life

  • icon08.svg
    • Suitable for various working conditions with soft and hard sealing for selection and hardenable sealing surface

  • icon09.svg
    • Both adjustment and cut-off functions supported

  • icon10.svg
    • Valve body of a larger thickness available to extend the scouring life according to the site conditions

Technical Data

  • Nominal Diameter

    DN25 ~ DN300, NPS 1'' ~ 12''

  • Nominal Pressure

    PN16 ~ PN63, ASME CL150 ~ CL300

  • Temperature Range

    -100° C ~ +525° C

  • Standard

    Complying with GB, ANSI and other standards

  • Supporting Actuator

    Matching with 830 angle actuator/A840 actuator
