A780 Fluorine Lined Butterfly Valve
Product Description
Valves to control strong corrosive media, also suitable for urban water plants and sewage treatment systems.
Features
-
Valve body made of PTFE or PFA lined cast steel available
-
PTFE lined valve body inner cavity and valve plate, ensuring no contact between the media and metal
-
Elastic compensation type sealing mechanism for the sealing surface of valve seat and valve plate, providing superior valve sealing performance
-
Compact and simple structure, light weight, small resistance and large flow capacity
Technical Data
-
Nominal Diameter
DN40 ~ DN800, NPS 1.5'' ~ 32''
-
Nominal Pressure
PN10 ~ PN16, ASME CL150
-
Temperature Range
-20° C ~ +150° C
-
Standards
Complying with GB, ANSI and other standards
-
Supporting Actuator
Matching with 830 series compact cylinder actuator and various types of electric actuators
