A760 Triple Eccentric Butterfly Valve
Product Description
Control valves for applications that require tight cut-off and low adjustment requirements in various industries.
Features
-
Triple eccentric and conical sealing structure; sealing pair that will become tighter and tighter; and effective removal of the scaling on the valve seat
-
Suitable for different working conditions with multi-layer hard sealing and pure metal sealing both available
-
Simple structure, small volume, light weight and small mounting dimension
-
Small driving force, easy operation and swift response
Technical Data
-
Nominal Diameter
DN80 ~ DN800, NPS 3'' ~ 32''
-
Nominal Pressure
PN16 ~ PN63, ASME CL150 ~ CL300
-
Temperature Range
-45° C ~ +525° C
-
Standards
Complying with GB, ANSI and other standards
-
Supporting Actuator
Matching with 830/830 (shift fork) cylinder actuator
