ZZCP/ZZVP Self-operated Differential/Micro Pressure Control Valve

Product Description

Control valves applied to occasions where there is no external energy on site, the pressure difference is very low, and automatic pressure stabilization control is required.

ZZCP ZZVP.png

Features

  • icon04.svg
    • Various valve body materials for selection, such as cast steel, cast stainless steel, low-temperature and high-alloy steel or special materials

  • icon05.svg
    • No external energy required, with the pressure difference between one or two media being adjusted automatically, so as to maintain a constant pressure difference

  • icon06.svg
    • Extremely sensitive actuator elements, being capable of sensing very small pressure changes

  • icon07.svg
    • Convenient pressure regulation, allowing adjustment of the setting value without interrupting manufacturing

Technical Data

  • Nominal Diameter

    DN20 ~ DN150, NPS 3/4'' ~ 6''

  • Nominal Pressure

    PN16, ASME CL150

  • Medium Temperature

    -40° C ~ +80° C
